GrayPane – Flight Search & Alerts

Code: github.com/punitarani/flights-tracker

Overview

GrayPane is a full‑stack flight discovery and alerting system. It enables users to search routes, track fare trends, explore award availability (via seats.aero), and receive scheduled email alerts. The app uses a typed API layer, durable background workflows, and a PostgreSQL schema designed for idempotent processing and auditability.

• Frontend: Next.js 15, React 19, Tailwind CSS, Radix UI, TanStack Query, next-themes, Sonner
• API: tRPC routers with Zod validation, Next.js Server Actions
• Workers: Cloudflare Workers + Workflows + Queues for alert processing and seats.aero ingestion
• DB: PostgreSQL via Drizzle ORM with prefixed ULID identifiers; JSONB alert filters
• Auth: Supabase with SSR
• Email: Resend for notifications
• Observability: Sentry for errors and performance
• Tooling: TypeScript, Bun test runner, Biome formatter/linter

System Architecture

At a high level, the system separates user‑facing interactions from durable background processing:

1. User interacts with the Next.js app (search flights, manage alerts)
2. API layer (tRPC) validates inputs, persists data, and orchestrates background work
3. Cloudflare Workflows run on cron and via queues to process alerts at scale
4. Workers call the app’s flight API for fresh data, apply alert rules, and send emails via Resend

Architecture Diagram (Workers Flow)

API & Service Layer

• tRPC Routers: src/server/routers/* provide typed endpoints for alerts, flights, airports, and seats.aero integration
• Validation: Zod schemas (e.g., versioned filters) ensure safe, forward‑compatible inputs
• Server Actions: Mutations use Next.js server actions where appropriate for minimal overhead

Core Services (Shared Between App and Workers)

Core business logic is implemented under src/core/ and reused by Workers via thin adapters:

• alerts-service.ts – high‑level alert operations
• alerts.db.ts, notifications.db.ts – DB operations
• seats-aero.db.ts – award availability data management
• filters.ts, alert-filter-utils.ts, alert-defaults.ts – versioned, typed alert filter model
• alert-processing-service.ts, alert-flight-fetcher.ts – flight matching and fetching orchestration

Adapters in src/workers/adapters/ wrap these services for the Worker runtime, keeping Cloudflare‑specific code small.

Data Model Highlights

• Alerts: Persisted with JSONB filter payloads (versioned) for schema agility
• Notifications: Email sends recorded for 24‑hour gating and audit
• Seats.aero: Requests and individual trips stored to support async fetching and incremental progress

Alert Processing (Cloudflare Workers)

• Workflows: check-flight-alerts and process-flight-alerts coordinate user batching and per‑user processing
• Queues: flights-tracker-alerts-queue limits concurrency (10 users) and enables backpressure
• Idempotency: Workflow instance IDs encode user and date; duplicates are safely ignored
• Time Windows: Email delivery only within 18:00–21:59 UTC and max once per 24h per user
• Observability: Sentry traces, logs, and error capture across handlers and steps

Seats.aero Async Search

A dedicated Workflow seats-aero-search processes award availability:

• Triggered by a tRPC call → Worker HTTP endpoint
• Paginates seats.aero API, stores trips in DB, and updates progress
• Frontend polls status (TanStack Query) until completion for a smooth UX

Engineering Practices

• Type-safety end-to-end: tRPC + Zod + Drizzle keep contracts, validation, and schema aligned
• Observability by default: Sentry traces span API and Workers for root-cause analysis
• Deterministic workflows: Idempotent instance IDs and explicit email gating windows
• Fast feedback: Bun tests for Workers and core modules run in <100ms locally
• Single-package reuse: Workers import src/core/* to avoid duplication

End-to-End Flow (User Perspective)

1. Create alert(s) with typed filters (route, dates, price, cabin, stops)
2. Cron schedules per-user processing via Cloudflare Queue (max 10 concurrent)
3. Worker fetches fresh flights, matches filters, dedupes, records notification
4. If eligible (6–9 PM UTC, >24h since last email), send a single daily email

References

• Source: punitarani/flights-tracker
• Workers design: docs/workflows.md
• Core modules: src/core/*
• Worker adapters/utils: src/workers/adapters/*, src/workers/utils/*
